SKU: CNBH-40
Major Brand CNBH40 Heavy Duty Slotted Cylindrical Cam Follower 1-1/4 inch Outside Diameter Allow 7-10 Days
- Regular price
- $55.37 ex VAT
- Sale price
- $55.37
- Regular price
-
Not in stock
Quantity Price Breaks
3
$49.28
4
$46.51
9
$45.96
19
$45.40
29
$44.85
39
$44.30
49
$41.53
59
$40.97
249
$40.42
499
$39.87
999
$38.76
SKU:
CNBH-40
Major Brand CNBH40 Heavy Duty Slotted Cylindrical Cam Follower 1-1/4 inch Outside Diameter Allow 7-10 Days
- Regular price
- $55.37 ex VAT
- Sale price
- $55.37
- Regular price
-
Description
|
Heavy Duty Cam Follower with Slotted Head: The outer race of this cam follower is high carbon chrome bearing steel through-hardened and ground. The studs and inner races are low carbon alloy steel carburized and induction hardened. This bearing contains a polymer type, lithium based grease containing corrosion resistant additives. This lubricant is suited to most bearing applications within a temperature range of 0 deg F to 250 deg F. Benefits: Suitable for many cam or track roller applications with moderate loading and shock. |
Technical
| A | = | 1.25 inch |
| B | = | 0.75 inch |
| C | = | 0.75 inch |
| D | = | 1.25 inch |
| E | = | 0.625 inch |
| Thread class 2A F | = | 3/4-16 UNF |
| G | = | 5/16 inch |
| H | = | 3/32 inch |
| J | = | 3/16 inch |
| Min boss diameter | = | 63/64 inch |
| Recommended bore | = | 0.75 inch |
| Recommended torque | = | 1250 lbf-in |
| Max static capacity | = | 8500 lbs |
| Basic dynamic rating | = | 3930 lbs |
