10AT5/690/G3 ContiTech Gen III Synchroflex Timing Belt 10mm Width 5mm Pitch 138 Teeth

SKU: 10AT5/690/G3

10AT5/690/G3 ContiTech Gen III Synchroflex Timing Belt 10mm Width 5mm Pitch 138 Teeth

$33.89 ex VAT
$33.89
ex VAT
Not in stock

Quantity Price Breaks

3 $30.16
5 $28.47
10 $28.13
15 $27.79
20 $27.45
30 $27.11
40 $25.42
50 $25.08
60 $24.74
75 $24.40
100 $23.72
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
10AT5/690/G3 ContiTech Gen III Synchroflex Timing Belt 10mm Width 5mm Pitch 138 Teeth
SKU: 10AT5/690/G3

10AT5/690/G3 ContiTech Gen III Synchroflex Timing Belt 10mm Width 5mm Pitch 138 Teeth

$33.89 ex VAT
$33.89
ex VAT

Description

AT Generation 3 SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.

The Generation 3 (Gen III) Synchroflex belt construction consists of high-tensile steel cord tension members and wear-resistant polyurethane which makes this belt extremely durable and provides high performance. Also, this belt provides an impressive 25% increase in power transmission when compared to the AT/ATP standard.

Benefits: Low elastic elongation, high flank load capacity, 25% more power than standard AT and high-performance polyurethane & steel reinforced.

Technical

No of Teeth = 138
Belt Width = 10mm
Belt Pitch = 5mm (AT5)
Belt Length = 690mm
Belt Thickness (hs) = 1.5mm
Tooth Height (ht) = 1.2mm
Tooth Pitch (t) = 5mm
Flank Angle (f) = 50 deg
Tension Member Loadings = 787 N
Belt Weight (per metre) = 0.036kg
