SKU: 10B-2-NO30-MB
Branded 10B-2-NO30 BS Duplex Chain Double Cranked Link 5/8 inch Pitch
- Regular price
- $8.42 ex VAT
- Sale price
- $8.42
- Regular price
-
In stock
Quantity Price Breaks
2
$7.49
5
$7.07
10
$6.99
29
$6.90
49
$6.82
75
$6.74
100
$6.32
200
$6.23
250
$6.15
500
$6.06
1000
$5.89
SKU:
10B-2-NO30-MB
Branded 10B-2-NO30 BS Duplex Chain Double Cranked Link 5/8 inch Pitch
- Regular price
- $8.42 ex VAT
- Sale price
- $8.42
- Regular price
-
Description
Branded DOL / No. 30 European (BS) Duplex Connecting Link: Double cranked links are available for most sizes and types of chain. The unit consists of an inner link (No. 4), with cranked links retained permanently in position by a riveted bearing pin.
Technical
| Pitch (A) | = | 0.625 inch |
| Pitch (A) | = | 15.875mm |
| Inside Width min (B) | = | 9.65mm |
| Roller Diameter max (C) | = | 10.16mm |
| Plate Height max (D) | = | 14.7mm |
| Plate Width Inner max (E) | = | 1.65mm |
| Plate Width Outer max (F) | = | 1.65mm |
| Pin Diameter max (G) | = | 5.08mm |
| Pin Length max (H2) | = | 36.2mm |
| Connecting Link Extension max (J) | = | 1.3mm |
| Transverse Pitch nom (K) | = | 16.59mm |
| ISO606 Tensile Strength min | = | 44500 N |
| Weight | = | 0.009kg/m |
