• Branded 12B-3 BS Triplex Roller Chain 3/4 inch Pitch 5 Metres
1 1

SKU: 12B-3-5MTR-MB

Branded 12B-3 BS Triplex Roller Chain 3/4 inch Pitch 5 Metres

Branded 12B-3 BS Triplex Roller Chain 3/4 inch Pitch 5 Metres
$217.16 ex VAT
$217.16 ex VAT
Sale Sold out

In stock

Price Break
2+ $145.46
5+ $137.29
10+ $135.65
29+ $134.02
49+ $132.38
75+ $130.75
100+ $122.58
200+ $120.94
250+ $119.31
500+ $117.67
1000+ $114.41

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Pitch:
19.05mm = 0.75 (3/4) inch
Technical
Pitch (P) 19.05mm = 0.75 (3/4) inch
Roller Diameter (D1 max) 12.07mm
Width between inner plates (B1 min) 11.68mm
Pin dia meter (D2 max) 5.72mm
Pin length (L max) 61.5mm
Pin length (Lc max) 63.1mm
Inner plate depth (H2 max) 16mm
Plate thickness (T max) 1.85mm
Ultimate tensile strength (Q min) kN/LB 86.7/19705
Average tensile strength (Q0) kN 101.8
Transverse pitch (Pt) mm 19.46
Weight per meter (q) kg/m 3.46
