SKU: 15x25x7_TO_VI_NAK
NAK 15x25x7mm FKM Rubber Full Coverage Double Lip Rotary Shaft Oil Seal TO
- Regular price
- $12.95 ex VAT
- Sale price
- $12.95
- Regular price
-
Quantity Price Breaks
NAK 15x25x7mm FKM Rubber Full Coverage Double Lip Rotary Shaft Oil Seal TO
- Regular price
- $12.95 ex VAT
- Sale price
- $12.95
- Regular price
-
Description
NAK TO FKM Oil Seals: Oil seals are used in a variety of different applications in which a rotating shaft is lubricated by oil or grease. They are engineered to facilitate the smooth operation of your equipment, serving as a barrier to prevent the leakage of oils and greases while also keeping foreign substances from entering. TO seals are produced using new injection molding machines which fully cover the exterior of the seal with rubber to eliminate the risk of rusting. They have a rubber-covered outside diameter and features a sealing FKM rubber lip on the inside diameter as well as an external dust lip. The TO types feature a garter spring which allows some give to prevent a build-up of friction. (Seals under 5mm width may not always feature a spring.)
Benefits: High-temperature range, Chemical resistance, Higher wear resistance, Lower drag coefficient.
Technical
| --- | = | Dimensions |
| Shaft Size (not inside diameter) d | = | 15mm |
| Outside Diameter (D) | = | 25mm |
| Width (b) | = | 7mm |
| --- | = | Material |
| Material | = | FKM Rubber |
| Spring Material | = | Carbon Steel |
| = | Colour | |
| Brown | = | --- |
| Weights | = | Weight |
| 0.01 kg | = | N/A |
