SKU: 16006-NTN

NTN 16006 Open Type Deep Groove Ball Bearing 30x55x9mm

NTN 16006 Open Type Deep Groove Ball Bearing 30x55x9mm
$15.67 ex VAT
$15.67 ex VAT
Sale Sold out

Equivalent to: 16006CM EL30 ELL30

In stock

Price Break
3+ $10.49
5+ $9.90
10+ $9.79
25+ $9.67
49+ $9.55
74+ $9.43
99+ $8.84
199+ $8.72
249+ $8.61
499+ $8.49
999+ $8.25

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NTN - High Quality
Inside Diameter:
30mm
Outside Diameter:
55mm
Width:
9mm
Seals / Shields:
None
Clearance:
* Standard
Technical
--- Bearing dimensions
d 30mm
D 55mm
B 9mm
r<sub>s</sub> min 0.3mm
--- Loads angles and speeds
C<sub>r</sub> 12.5 kN
C<sub>or</sub> 7.35 kN
C<sub>u</sub> 0.57 kN
f<sub>0</sub> 15.2 kN
Grease 13000 rpm
Oil 15000 rpm
--- Fitting Dimensions
d<sub>a</sub> Min. 32mm
D<sub>a</sub> Max. 53mm
r<sub>as</sub> Max. 0.3mm
Weight 0.091 kg
