SKU: 16010-NTN

NTN 16010 Open Type Deep Groove Ball Bearing 50x80x10mm

NTN 16010 Open Type Deep Groove Ball Bearing 50x80x10mm
$23.60 ex VAT
$23.60 ex VAT
Sale Sold out

Equivalent to: 16010CM ELN50 ELLN50

In stock

Price Break
3+ $15.81
5+ $14.92
10+ $14.74
25+ $14.56
49+ $14.39
74+ $14.21
99+ $13.32
199+ $13.14
249+ $12.96
499+ $12.79
999+ $12.43

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NTN - High Quality
Inside Diameter:
50mm
Outside Diameter:
80mm
Width:
10mm
Seals / Shields:
None
Clearance:
* Standard
Technical
--- Bearing dimensions
d 50mm
D 80mm
B 10mm
r<sub>s</sub> min 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 14.7 kN
C<sub>or</sub> 11.3 kN
C<sub>u</sub> 0.76 kN
f<sub>0</sub> 16.4 kN
Grease 8400 rpm
Oil 9800 rpm
--- Fitting Dimensions
d<sub>a</sub> Min. 54mm
D<sub>a</sub> Max. 76mm
r<sub>as</sub> Max. 0.6mm
Weight 0.18 kg
