• NTN 16014 Open Type Deep Groove Ball Bearing 70x110x13mm
  • NTN 16014 Open Type Deep Groove Ball Bearing 70x110x13mm
  • NTN 16014 Open Type Deep Groove Ball Bearing 70x110x13mm
  • NTN
1 4

SKU: 16014-NTN

NTN 16014 Open Type Deep Groove Ball Bearing 70x110x13mm

NTN 16014 Open Type Deep Groove Ball Bearing 70x110x13mm
$44.56 ex VAT
$44.56 ex VAT
Sale Sold out

Equivalent to: 16014CM ELN70 ELLN70

In stock

Price Break
3+ $29.85
5+ $28.17
10+ $27.84
25+ $27.50
49+ $27.17
74+ $26.83
99+ $25.16
199+ $24.82
249+ $24.48
499+ $24.15
999+ $23.48

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
NTN - High Quality
Inside Diameter:
70mm
Outside Diameter:
110mm
Width:
13mm
Seals / Shields:
None
Clearance:
* Standard
Technical
--- Bearing dimensions
d 70mm
D 110mm
B 13mm
r<sub>s</sub> min 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 27 kN
C<sub>or</sub> 22.6 kN
C<sub>u</sub> 1.52 kN
f<sub>0</sub> 16.5 kN
Grease 6100 rpm
Oil 7100 rpm
--- Fitting Dimensions
d<sub>a</sub> Min. 74mm
D<sub>a</sub> Max. 106mm
r<sub>as</sub> Max. 0.6mm
Weight 0.441 kg
