SKU: 1726212-2RS1-SKF
SKF 17262122RS1 Spherical Outside Dia Deep Groove Ball Bearing 60x110x22mm
SKF 17262122RS1 Spherical Outside Dia Deep Groove Ball Bearing 60x110x22mm
Regular price
$64.52
ex VAT
Regular price
Sale price
$64.52
ex VAT
In stock
Price Break
10+
$43.22
20+
$40.79
30+
$40.31
40+
$39.82
50+
$39.34
75+
$38.85
100+
$36.42
200+
$35.94
250+
$35.45
500+
$34.97
1000+
$33.99
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
172 Series Rubber Sealed Deep Groove Ball Bearings with Spherical Outer Race: Commonly used in conjunction with pressed steel bearing housings or cast iron types these rubber sealed bearings are characterized by their spherical outside diameter. |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 110mm
- Width:
- 22mm
- Seals / Shields:
- Rubber Sealed
Technical
Technical
| d | 60mm |
|---|---|
| D | 110mm |
| B | 22mm |
| d1 | 75.5mm |
| r1r2 min | 1.5mm |
| Static load Cr | 36 kN |
| Dynamic load Cor | 52.7 kN |
| Fatigue load limit Pu | 1.53 kN |
| Limiting speed | 4000 rpm |
| Weight | 0.7 kg |
