• 22002RS Budget Rubber Sealed Self Aligning Ball Bearing 10x30x13mm
1 1

SKU: 2200-2RS-EU

22002RS Budget Rubber Sealed Self Aligning Ball Bearing 10x30x13mm

22002RS Budget Rubber Sealed Self Aligning Ball Bearing 10x30x13mm
$16.18 ex VAT
$16.18 ex VAT
Sale Sold out

In stock

Price Break
10+ $10.84
19+ $10.23
29+ $10.11
39+ $9.99
49+ $9.86
74+ $9.74
99+ $9.13
199+ $9.01
249+ $8.89
499+ $8.77
999+ $8.52

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Rubber Sealed Self Aligning Ball Bearings: This bearing series has two rows of balls running on the same spherical outer raceway, this makes the bearing self aligning, self centering and insensitive to angular misalignment. They are particularly suited to applications where considerable shaft deflections are anticipated. Self aligning ball bearings have the lowest rolling friction of all rolling bearings and are the coolest running bearing type even at high speeds. Supplied with two rubber seals this provided protection from the surrounding environment but limits the amount of self alignment
Benefits: Tolerates misalignment, cool running, self centering
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
10mm
Outside Diameter:
30mm
Width:
13mm
Seals / Shields:
Rubber Sealed
Clearance:
* Standard
Technical
--- Dimensions
d 10mm
D 30mm
B 13mm
D1 24.8mm
d2 13mm
r1r2 0.6mm
da min 13mm
da max 13mm
Da max 25.8mm
ra max 0.6mm
--- Calculation Data
C 5.53kN
Co 1.18kN
Pu 0.06kN
limit 17000rpm
e 0.33
Y1 1.9
Y2 3
Y0 2
--- Weights
mass 0.048kg
