• 2209K2RS Rubber Sealed Self Aligning Ball Bearing with Taper Bore 45x85x23mm
1 1

SKU: 2209.K.2RS.MB

2209K2RS Rubber Sealed Self Aligning Ball Bearing with Taper Bore 45x85x23mm

2209K2RS Rubber Sealed Self Aligning Ball Bearing with Taper Bore 45x85x23mm
$66.12 ex VAT
$66.12 ex VAT
Sale Sold out

Equivalent to: 2209EK2RS 2209K-2RS

In stock

Price Break
10+ $44.29
19+ $41.80
29+ $41.30
39+ $40.80
49+ $40.30
74+ $39.81
99+ $37.32
199+ $36.82
249+ $36.32
499+ $35.83
999+ $34.83

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Rubber Sealed Self Aligning Ball Bearings: This bearing series has two rows of balls running on the same spherical outer raceway, this makes the bearing self aligning, self centering and insensitive to angular misalignment. They are particularly suited to applications where considerable shaft deflections are anticipated. Self aligning ball bearings have the lowest rolling friction of all rolling bearings and are the coolest running bearing type even at high speeds. Supplied with two rubber seals this provided protection from the surrounding environment but limits the amount of self alignment
Benefits: Tolerates misalignment, cool running, self centering
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
45mm
Outside Diameter:
85mm
Width:
23mm
Seals / Shields:
Rubber Sealed
Clearance:
* Standard
Technical
--- Dimensions
d 45mm
D 85mm
B 23mm
r1r2 min 1.1mm
--- Speeds, Loads and Weights
Dynamic Load 23.5kN
Static Load 8.2kN
Pu 0.4Kn
Limiting Speed 10000rpm
Weight 0.55kg
--- Factors
e 0.21
Fa/Fr = e 3
Fa/Fr > e 4.7
Y0 3.2
--- Matching Adaptor Sleeves
Adaptor Sleeve <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H309C+sleeve>H309C</a>
Adaptor Sleeve <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H309E+sleeve>H309E</a>
