SKU: 2209K-2RS-EU

2209K2RS Budget Rubber Sealed Self Aligning Ball Bearing with Taper Bore 45x85x23mm

Name: 2209K2RS Budget Rubber Sealed Self Aligning Ball Bearing with Taper Bore 45x85x23mm
Brand: Gen
SKU: 2209K-2RS-EU
Price: 40.49 USD
Availability: InStock

$40.49 ex VAT

Sale Sold out

Equivalent to: 2209EK2RS

In stock

Price Break

10+ $27.12

19+ $25.59

29+ $25.29

39+ $24.99

49+ $24.68

74+ $24.38

99+ $22.85

199+ $22.55

249+ $22.24

499+ $21.94

999+ $21.33

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 45mm
Outside Diameter:: 85mm
Width:: 23mm
Seals / Shields:: Rubber Sealed
Clearance:: * Standard

Technical

---	Dimensions
d	45mm
D	85mm
B	23mm
D1	75.3mm
d2	53.1mm
r1r2	1.1mm
da min	52mm
da max	53mm
Da max	78mm
ra max	1mm
---	Calculation Data
C	22.9kN
Co	7.8kN
Pu	0.4kN
limit	5300rpm
e	0.21
Y1	3
Y2	4.6
Y0	3.2
---	Weights
mass	0.53kg
---	Matching Adaptor Sleeves
Sleeve No.	<a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H309C+sleeve>H309C</a>
Sleeve No.	<a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H309E+sleeve>H309E</a>
