• 22122RS Budget Rubber Sealed Self Aligning Ball Bearing 60x110x28mm
1 1

SKU: 2212-2RS-EU

22122RS Budget Rubber Sealed Self Aligning Ball Bearing 60x110x28mm

22122RS Budget Rubber Sealed Self Aligning Ball Bearing 60x110x28mm
$62.29 ex VAT
$62.29 ex VAT
Sale Sold out

In stock

Price Break
10+ $41.72
19+ $39.38
29+ $38.91
39+ $38.44
49+ $37.97
74+ $37.50
99+ $35.16
199+ $34.69
249+ $34.22
499+ $33.75
999+ $32.81

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Rubber Sealed Self Aligning Ball Bearings: This bearing series has two rows of balls running on the same spherical outer raceway, this makes the bearing self aligning, self centering and insensitive to angular misalignment. They are particularly suited to applications where considerable shaft deflections are anticipated. Self aligning ball bearings have the lowest rolling friction of all rolling bearings and are the coolest running bearing type even at high speeds. Supplied with two rubber seals this provided protection from the surrounding environment but limits the amount of self alignment
Benefits: Tolerates misalignment, cool running, self centering
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
60mm
Outside Diameter:
110mm
Width:
28mm
Seals / Shields:
Rubber Sealed
Clearance:
* Standard
Technical
--- Dimensions
d 60mm
D 110mm
B 28mm
D1 97mm
d2 73.2mm
r1r2 1.5mm
da min 69mm
da max 73mm
Da max 101mm
ra max 1.5mm
--- Calculation Data
C 31.2kN
Co 12.2kN
Pu 0.62kN
limit 3800rpm
e 0.19
Y1 3.3
Y2 5.1
Y0 3.6
--- Weights
mass 1.05kg
