• 23062RS Rubber Sealed Self Aligning Ball Bearing 30x72x27mm
1 1

SKU: 2306.2RS.MB

23062RS Rubber Sealed Self Aligning Ball Bearing 30x72x27mm

23062RS Rubber Sealed Self Aligning Ball Bearing 30x72x27mm
$66.86 ex VAT
$66.86 ex VAT
Sale Sold out

In stock

Price Break
10+ $44.79
19+ $42.27
29+ $41.77
39+ $41.27
49+ $40.76
74+ $40.26
99+ $37.74
199+ $37.24
249+ $36.74
499+ $36.23
999+ $35.23

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Rubber Sealed Self Aligning Ball Bearings: This bearing series has two rows of balls running on the same spherical outer raceway, this makes the bearing self aligning, self centering and insensitive to angular misalignment. They are particularly suited to applications where considerable shaft deflections are anticipated. Self aligning ball bearings have the lowest rolling friction of all rolling bearings and are the coolest running bearing type even at high speeds. Supplied with two rubber seals this provided protection from the surrounding environment but limits the amount of self alignment
Benefits: Tolerates misalignment, cool running, self centering
Brand / Quality:
Major Brand - High Quality
Inside Diameter:
30mm
Outside Diameter:
72mm
Width:
27mm
Seals / Shields:
Rubber Sealed
Clearance:
* Standard
Technical
d 30
D 72
B 27
r1r2 min 1.1
Dynamic load 21.3 kn
Static load 6.3 kN
Cu 0.3 kN
Reference speed - rpm
Limiting speed 13000 rpm
Weight 0.5kg
e 0.26
Fa/Fr = e 2.4
Fa/Fr > e 3.7Y0
2.5 N/A
