• FAG 234420MSP Super Precision Double Axial Angular Contact Spindle Bearing 100x150x60mm
  • FAG
1 2

SKU: 234420-M-SP-FAG

FAG 234420MSP Super Precision Double Axial Angular Contact Spindle Bearing 100x150x60mm

FAG 234420MSP Super Precision Double Axial Angular Contact Spindle Bearing 100x150x60mm
$1,099.88 ex VAT
$1,099.88 ex VAT
Sale Sold out

In stock

Price Break
3+ $736.73
5+ $695.34
10+ $687.07
25+ $678.79
49+ $670.51
74+ $662.23
99+ $620.84
199+ $612.56
249+ $604.29
499+ $596.01
999+ $579.45

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
FAG - High Quality
Inside Diameter:
100mm
Outside Diameter:
150mm
Width:
60mm
Seals / Shields:
None
Style:
Precision Angular Contact Spindle Bearings
Contact Angle:
60 Degree contact angle
Technical
--- Bearing dimensions
d 100mm
D 150mm
B 60mm
C 30mm
d<sub>1</sub> 133mm
B<sub>1</sub> 15mm
r<sub> min</sub> 1.5mm
r<sub>1 min</sub> 0.3mm
--- Abutment dimensions
d<sub>s</sub> 4.8mm
n<sub>s</sub> 9.5mm
d<sub>a</sub> h12 120.5mm
D<sub>a</sub> H12 140.5mm
r<sub>a max</sub> 1.5mm
r<sub>a1 max</sub> 0.3mm
--- Speeds, weights and loads
Dynamic load C<sub>a</sub> 67000 N
Static load C<sub>oa</sub> 226000 N
Speed in grease <sub>ng</sub> 3800 rpm
Speed in oil <sub>ng</sub> 5000 rpm
prelaod force F<sub>v</sub> 685 N
Lift off force K<sub>aE</sub> 1956 N
Axial rigidity C<sub>a</sub> 843 N/&mu;m
Weight 3.17kg
