• 250X4SPB 250mm Pitch Diameter SPB Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
  • 250X4SPB 250mm Pitch Diameter SPB Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
1 2

SKU: 250SPB4-MB

250X4SPB 250mm Pitch Diameter SPB Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)

250X4SPB 250mm Pitch Diameter SPB Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
$112.85 ex VAT
$112.85 ex VAT
Sale Sold out

In stock

Price Break
3+ $75.59
5+ $71.34
9+ $70.49
19+ $69.64
49+ $68.79
74+ $67.94
99+ $63.70
199+ $62.85
249+ $62.00
499+ $61.15
999+ $59.45

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Grooves:
4
Outside Diameter:
257.6mm
Pitch Diameter:
250mm
Max Bore:
75mm
Technical
Number of Grooves 4
Bush <a href="advanced_search_result.php?sort=2a&search_in_description=1&keywords=3020+tapered+locking+bush">3020 Click Here</a>
Pitch Diameter B 250mm
Overall Outer Diameter C 257.6mm
Max Bore A 75mm
Outer Hub Diameter E 144mm
Overall Sheave Depth F 82mm
Bush Seat Length G 51mm
Inner Recess Diameter D 207mm
Inner Recess Length H 15.5mm
