• SKF 29330E Spherical Roller Thrust Bearing 150x250x60mm
1 1

SKU: 29330E-SKF

SKF 29330E Spherical Roller Thrust Bearing 150x250x60mm

SKF 29330E Spherical Roller Thrust Bearing 150x250x60mm
$1,711.27 ex VAT
$1,711.27 ex VAT
Sale Sold out

In stock

Price Break
10+ $1,146.09
19+ $1,081.70
29+ $1,068.82
39+ $1,055.95
49+ $1,043.07
74+ $1,030.19
99+ $965.80
199+ $952.93
249+ $940.05
499+ $927.17
999+ $901.42

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Spherical Roller Thrust Bearings: These bearings are thrust bearings that have self aligning ability as as such will tolerate misalignment and deal with both axial and radial loads simultaneously.
Benefits: High radial and axial loads, misalignment
Brand / Quality:
SKF - High Quality
Inside Diameter:
150mm
Outside Diameter:
250mm
Width:
60mm
Technical
d 150mm
D 250mm
H 60mm
Dynamic load C 1000 kN
Static load Co 2850 kN
Fatigue load limit Pu 315 kN
Minimum load factor A 0.77
Reference speed 1500 rpm
Limiting speed 2400 rpm
Weight 11 kg
d1 223.9mm
D1 190mm
B 38mm
B1 54.9mm
C 28mm
s 87mm
r1r2 min 2.1mm
da min 195mm
db1 max 158mm
db2 max 163mm
Da max 219mm
ra max 2mm
