SKU: 293500-SKF

SKF 293500 Spherical Roller Thrust Bearing 500x750x150mm

Name: SKF 293500 Spherical Roller Thrust Bearing 500x750x150mm
Brand: SKF
SKU: 293500-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Spherical Roller Thrust Bearings: These bearings are thrust bearings that have self aligning ability as as such will tolerate misalignment and deal with both axial and radial loads simultaneously.
Benefits: High radial and axial loads, misalignment

Brand / Quality:: SKF - High Quality
Inside Diameter:: 500mm
Outside Diameter:: 750mm
Width:: 150mm

Technical

d	500mm
D	750mm
H	150mm
Dynamic load C	4490 kN
Static load Co	20400 kN
Fatigue load limit Pu	1560 kN
Minimum load factor A	40
Reference speed	430 rpm
Limiting speed	800 rpm
Weight	235 kg
d1	725mm
D1	611mm
B	50mm
B1	144mm
C	74mm
s	280mm
r1r2 min	6mm
da min	630mm
Da max	675mm
ra max	5mm
