SKU: 29452E-SKF

SKF 29452E Spherical Roller Thrust Bearing 260x480x132mm

Name: SKF 29452E Spherical Roller Thrust Bearing 260x480x132mm
Brand: SKF
SKU: 29452E-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Spherical Roller Thrust Bearings: These bearings are thrust bearings that have self aligning ability as as such will tolerate misalignment and deal with both axial and radial loads simultaneously.
Benefits: High radial and axial loads, misalignment

Brand / Quality:: SKF - High Quality
Inside Diameter:: 260mm
Outside Diameter:: 480mm
Width:: 132mm

Technical

d	260mm
D	480mm
H	132mm
Dynamic load C	4050 kN
Static load Co	12900 kN
Fatigue load limit Pu	1080 kN
Minimum load factor A	16
Reference speed	750 rpm
Limiting speed	1300 rpm
Weight	105 kg
d1	427.9mm
D1	346mm
B	86mm
B1	119mm
C	63mm
s	154mm
r1r2 min	6mm
da min	365mm
db1 max	278mm
db2 max	296mm
Da max	412mm
ra max	5mm
