SKU: 29460E-SKF

SKF 29460E Spherical Roller Thrust Bearing 300x540x145mm

Name: SKF 29460E Spherical Roller Thrust Bearing 300x540x145mm
Brand: SKF
SKU: 29460E-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Spherical Roller Thrust Bearings: These bearings are thrust bearings that have self aligning ability as as such will tolerate misalignment and deal with both axial and radial loads simultaneously.
Benefits: High radial and axial loads, misalignment

Brand / Quality:: SKF - High Quality
Inside Diameter:: 300mm
Outside Diameter:: 540mm
Width:: 145mm

Technical

d	300mm
D	540mm
H	145mm
Dynamic load C	4310 kN
Static load Co	16600 kN
Fatigue load limit Pu	1340 kN
Minimum load factor A	26
Reference speed	600 rpm
Limiting speed	1200 rpm
Weight	140 kg
d1	485mm
D1	392mm
B	95mm
B1	130.3mm
C	70.5mm
s	175mm
r1r2 min	6mm
da min	415mm
db1 max	319mm
db2 max	340mm
Da max	465mm
ra max	5mm
