SKF 294630EM Spherical Roller Thrust Bearing 630x1090x280mm

Name: SKF 294630EM Spherical Roller Thrust Bearing 630x1090x280mm
Brand: SKF
SKU: 294630EM-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Spherical Roller Thrust Bearings: These bearings are thrust bearings that have self aligning ability as as such will tolerate misalignment and deal with both axial and radial loads simultaneously.
Benefits: High radial and axial loads, misalignment

Brand / Quality:: SKF - High Quality
Inside Diameter:: 630mm
Outside Diameter:: 1090mm
Width:: 280mm

Technical

d	630mm
D	1090mm
H	280mm
Dynamic load C	14400 kN
Static load Co	62000 kN
Fatigue load limit Pu	4150 kN
Minimum load factor A	370
Reference speed	260 rpm
Limiting speed	500 rpm
Weight	1040 kg
d1	995mm
D1	815mm
B	107mm
B1	270mm
C	137mm
s	365mm
r1r2 min	12mm
da min	860mm
Da max	950mm
ra max	10mm
