• Budget 3000B2RSRTVH Rubber Sealed Double Row Angular Contact Ball Bearing 10x26x12mm
1 1

SKU: 3000.B.2RSR.TVH.EU

Budget 3000B2RSRTVH Rubber Sealed Double Row Angular Contact Ball Bearing 10x26x12mm

Budget 3000B2RSRTVH Rubber Sealed Double Row Angular Contact Ball Bearing 10x26x12mm
$7.63 ex VAT
$7.63 ex VAT
Sale Sold out

Equivalent to: 5000B2RSRTVH

In stock

Price Break
10+ $5.11
19+ $4.82
29+ $4.76
39+ $4.71
49+ $4.65
74+ $4.59
99+ $4.31
199+ $4.25
249+ $4.19
499+ $4.13
999+ $4.02

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Double Row Thin Section Sealed Angular Contact Ball Bearings: These bearings have large bore to outside diameter ratio and have internal raceways that are effectively opposite each other, they are designed to accommodate both axial and radial loads and have a tremendous load bearing capacity
Benefits: Compact, rigid, accommodates tilting, radial and axial loads, rubber seals
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
10mm
Outside Diameter:
26mm
Width:
12mm
Seals / Shields:
Rubber Sealed
Clearance:
* Standard
Technical
d 10mm
D 26mm
B 12mm
a 12.6mm
d1 max 21.2mm
Da max 24mm
da min 12mm
ra max 0.3mm
r min 0.3mm
Contact angle α 25°
Weight 0.022 kg
Dynamic load Cr 5700 N
Static load Cor 3200 N
Fatigue limit load Cur 166 N
Reference speed - rpm
Limiting Speed 18100 rpm
