• 315X4SPA 315mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
  • 315X4SPA 315mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
1 2

SKU: 315SPA4-MB

315X4SPA 315mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)

315X4SPA 315mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
$106.53 ex VAT
$106.53 ex VAT
Sale Sold out

In stock

Price Break
3+ $71.36
5+ $67.35
9+ $66.55
19+ $65.74
49+ $64.94
74+ $64.14
99+ $60.13
199+ $59.33
249+ $58.53
499+ $57.73
999+ $56.12

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Grooves:
4
Outside Diameter:
321.2mm
Pitch Diameter:
315mm
Max Bore:
75mm
Technical
Number of Grooves 4
Bush <a href="advanced_search_result.php?sort=2a&search_in_description=1&keywords=3020+tapered+locking+bush">3020 Click Here</a>
Pitch Diameter B 315mm
Overall Outer Diameter C 321.2mm
Max Bore A 75mm
Outer Hub Diameter E 159mm
Overall Sheave Depth F 65mm
Bush Seat Length G 51mm
Inner Recess Diameter D 280mm
Inner Recess Length H 7mm
