SKU: 3200-2RS-EU
32002RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 10x30x14mm
32002RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 10x30x14mm
Regular price
$21.41
ex VAT
Regular price
Sale price
$21.41
ex VAT
In stock
Price Break
10+
$14.33
19+
$13.53
29+
$13.37
39+
$13.21
49+
$13.05
74+
$12.89
99+
$12.08
199+
$11.92
249+
$11.76
499+
$11.60
999+
$11.27
Quantity
Couldn't load pickup availability
Share this product
Description
Description
DRACS1_DESC
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 10mm
- Outside Diameter:
- 30mm
- Width:
- 14mm
- Seals / Shields:
- Rubber Sealed
- Clearance:
- * Standard
Technical
Technical
| d | 10mm |
|---|---|
| D | 30mm |
| B | 14mm |
| Dynamic load C | 7.61 kN |
| Static load Co | 4.3 kN |
| Fatigue load limit Pu | 0.183 kN |
| Reference speed | 17000 rpm |
| Weight | 0.051 kg |
| d1 | 15.8mm |
| D1 | 25mm |
| r1r2 min | 0.6mm |
| a | 16mm |
| da min | 14.4mm |
| da max | 15.5mm |
| Da max | 25.6mm |
| ra max | 0.6mm |
Reviews
Reviews
☆☆☆☆☆ (0 total reviews)
