SKU: 3201-2RS-EU
32012RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 12x32x15.9mm
32012RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 12x32x15.9mm
Regular price
$21.83
ex VAT
Regular price
Sale price
$21.83
ex VAT
In stock
Price Break
10+
$14.62
19+
$13.80
29+
$13.64
39+
$13.47
49+
$13.31
74+
$13.14
99+
$12.32
199+
$12.16
249+
$11.99
499+
$11.83
999+
$11.50
Quantity
Couldn't load pickup availability
Share this product
Description
Description
DRACS1_DESC
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 12mm
- Outside Diameter:
- 32mm
- Width:
- 15.9mm
- Seals / Shields:
- Rubber Sealed
- Clearance:
- * Standard
Technical
Technical
| d | 12mm |
|---|---|
| D | 32mm |
| B | 15.9mm |
| Dynamic load C | 10.1 kN |
| Static load Co | 5.6 kN |
| Fatigue load limit Pu | 0.24 kN |
| Reference speed | 15000 rpm |
| Weight | 0.058 kg |
| d1 | 17.2mm |
| D1 | 27.7mm |
| r1r2 min | 0.6mm |
| a | 19mm |
| da min | 16.4mm |
| da max | 17mm |
| Da max | 27.7mm |
| ra max | 0.6mm |
