SKU: 3206NR/TN9-SKF
SKF 3206NRTN9 Double Row Angular Contact Ball Bearing with Snap Ring and Polyamide Cage 30x62x23.8mm - Allow 2-3 Days
SKF 3206NRTN9 Double Row Angular Contact Ball Bearing with Snap Ring and Polyamide Cage 30x62x23.8mm - Allow 2-3 Days
Regular price
$88.32
ex VAT
Regular price
Sale price
$88.32
ex VAT
Equivalent to: 5206
In stock
Price Break
4+
$65.80
8+
$63.14
12+
$61.81
16+
$59.81
25+
$58.48
50+
$55.16
99+
$46.52
199+
$0.00
249+
$0.00
499+
$0.00
999+
$0.00
Quantity
Couldn't load pickup availability
Description
Description
|
Open Type Double Row Angular Contact Ball Bearings with Snap Ring:?Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well. |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 30mm
- Outside Diameter:
- 62mm
- Width:
- 23.8mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 30mm |
|---|---|
| D | 62mm |
| B | 23.8mm |
| Dynamic load Cr | 30 kN |
| Static load Cor | 20.4 kN |
| Fatigue load limit Pu | 0.865 kN |
| Reference speed | 10000 rpm |
| Limiting speed | 10000 rpm |
| Weight | 0.29 kg |
| d1 | 38.7mm |
| D1 | 55.2mm |
| r1r2 min | 1mm |
| a | 36mm |
| da min | 35.6mm |
| Da max | 56.4mm |
| ra max | 1mm |
