SKU: 32911-MB
Major Brand 32911 Metric Taper Roller Bearing 55x80x17mm - Allow 2-3 Days
Major Brand 32911 Metric Taper Roller Bearing 55x80x17mm - Allow 2-3 Days
Equivalent to: 32911XU 32911JR 32911J
Out of stock
Description
Description
|
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer). Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 55mm
- Outside Diameter:
- 80mm
- Width:
- 17mm
- Seals / Shields:
- None
Technical
Technical
| Inner Diameter d | 55mm |
|---|---|
| Outer Diameter D | 80mm |
| Inner Ring width B | 17mm |
| Outer Ring Width C | 14mm |
| Total width T | 17mm |
| Maxium Shaft Link Radius r<sub>as</sub>max | 1mm |
| Maxium Housing Link Radius r<sub>1as</sub>max | 1mm |
| Weight | 0.274kg |
| Dynamic Load Capacity C | 44.5 kN |
| Static Load capacity C0 | 73.5 kN |
| Limit Speed with Grease LUB | 4300 rpm |
| Limit Speed with Oil LUB | 5700 rpm |
