• SKF 3306A2RS1TN9C3MT33 Double Row Angular Contact Ball Bearing with 2 Rubber Seals 30x72x30.2mm
1 1

SKU: 3306A-2RS1TN9/C3MT33-SKF

SKF 3306A2RS1TN9C3MT33 Double Row Angular Contact Ball Bearing with 2 Rubber Seals 30x72x30.2mm

SKF 3306A2RS1TN9C3MT33 Double Row Angular Contact Ball Bearing with 2 Rubber Seals 30x72x30.2mm
$114.29 ex VAT
$114.29 ex VAT
Sale Sold out

Equivalent to: 5306

In stock

Price Break
4+ $76.56
8+ $72.26
12+ $71.40
16+ $70.54
25+ $69.68
50+ $68.82
99+ $64.52
199+ $63.66
249+ $62.80
499+ $61.94
999+ $60.21

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Rubber Sealed Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well.
Benefits: Compact, rigid, accommodates tilting, radial and axial loads
Brand / Quality:
SKF - High Quality
Inside Diameter:
30mm
Outside Diameter:
72mm
Width:
30.2mm
Seals / Shields:
None
Clearance:
C3
Technical
d 30mm
D 72mm
B 30.2mm
Dynamic load Cr 41.5 kN
Static load Cor 27.5 kN
Fatigue load limit Pu 1.16 kN
Max speed 6300 rpm
Weight 0.52 kg
d1 39.8mm
D1 64.1mm
r1r2 min 1.1mm
a 42mm
da min 37mm
da max 39.5mm
Da max 65mm
ra max 1mm
