SKU: 3308-2RS-EU
33082RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 40x90x36.5mm
33082RS Budget Rubber Sealed Double Row Angular Contact Ball Bearing 40x90x36.5mm
Regular price
$66.87
ex VAT
Regular price
Sale price
$66.87
ex VAT
In stock
Price Break
10+
$44.79
19+
$42.28
29+
$41.77
39+
$41.27
49+
$40.77
74+
$40.26
99+
$37.75
199+
$37.24
249+
$36.74
499+
$36.24
999+
$35.23
Quantity
Couldn't load pickup availability
Share this product
Description
Description
DRACS1_DESC
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
Note: Due to the differences amongst the standard specifications of different brands, this bearing may come with a polyamide or steel cage. Please contact our Sales Support team if you need to check the specification before purchase.
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 40mm
- Outside Diameter:
- 90mm
- Width:
- 36.5mm
- Seals / Shields:
- Rubber Sealed
- Clearance:
- * Standard
Technical
Technical
| d | 40mm |
|---|---|
| D | 90mm |
| B | 36.5mm |
| Dynamic load C | 64 kN |
| Static load Co | 44 kN |
| Fatigue load limit Pu | 1.86 kN |
| Reference speed | 5000 rpm |
| Weight | 0.93 kg |
| d1 | 50.8mm |
| D1 | 80.5mm |
| r1r2 min | 1.5mm |
| a | 53mm |
| da min | 49mm |
| da max | 50.5mm |
| Da max | 81mm |
| ra max | 1.5mm |
