SKU: 3314A-2Z-SKF

SKF 3314A2Z Double Row Angular Contact Ball Bearing with 2 Metal Shields 70x150x63.5mm

Name: SKF 3314A2Z Double Row Angular Contact Ball Bearing with 2 Metal Shields 70x150x63.5mm
Brand: SKF
SKU: 3314A-2Z-SKF
Availability: OutOfStock

Equivalent to: 5314

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well.
Benefits: Compact, rigid, accommodates tilting, radial and axial loads

Brand / Quality:: SKF - High Quality
Inside Diameter:: 70mm
Outside Diameter:: 150mm
Width:: 63.5mm
Seals / Shields:: Metal Shielded
Clearance:: * Standard

Technical

d	70mm
D	150mm
B	63.5mm
Dynamic load Cr	163 kN
Static load Cor	125 kN
Fatigue load limit Pu	5 kN
Max speed	4300 rpm
Weight	5.05 kg
d1	84.2mm
D1	139mm
r1r2 min	2.1mm
a	89mm
da min	82mm
da max	84mm
Da max	139mm
ra max	2mm
