SKU: 36x44x5.7_UIP_NAK
NAK 36x44x5.7mm UIP Polyurethane Rod Seal - Allow 7-10 Days
- Regular price
- $4.55 ex VAT
- Sale price
- $4.55
- Regular price
-
Not in stock
Quantity Price Breaks
10
$4.05
19
$3.82
29
$3.78
39
$3.73
49
$3.69
74
$3.64
99
$3.41
199
$3.37
249
$3.32
499
$3.28
999
$3.19
SKU:
36x44x5.7_UIP_NAK
NAK 36x44x5.7mm UIP Polyurethane Rod Seal - Allow 7-10 Days
- Regular price
- $4.55 ex VAT
- Sale price
- $4.55
- Regular price
-
Description
NAK UIP Rod Seals: The UIP rod seal is a high-performance hydraulic sealing element developed by NAK for demanding rod-end applications. Featuring an asymmetric lip design, it delivers reliable sealing performance while offering enhanced protection against contamination and premature wear.
Benefits: Easy installation, extended operating life, low-friction operation even under high-speed conditions
Technical
| d | = | 36mm |
| D | = | 44mm |
| L | = | 6.4mm |
| h | = | 5.7mm |
| C | = | 2mm |
| Inside Diameter Tolerance | = | f8 |
| Outside Diameter Tolerance | = | H10 |
| Length Tolerance | = | 0.2mm |
| Pressure (max) | = | 40 Mpa |
| Sliding Speed (max) | = | 0.5 m/s |
| Temperature | = | -40 Deg C to +100 Deg C |
| Colour | = | Blue |
