• Renold Standard Duty 40-3 ANSI / AS Triplex Roller Chain 1/2 inch Pitch - 10 Feet Length
  • Renold
1 2

SKU: 40-3-SD-10FT-RENOLD

Renold Standard Duty 40-3 ANSI / AS Triplex Roller Chain 1/2 inch Pitch - 10 Feet Length

Renold Standard Duty 40-3 ANSI / AS Triplex Roller Chain 1/2 inch Pitch - 10 Feet Length
$91.04 ex VAT
$91.04 ex VAT
Sale Sold out

Equivalent to: SD40-3

In stock

Price Break
0+ $0.00

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Renold - High Quality
Pitch:
12.7mm = 0.5 (1/2) inch
Technical
Pitch (A) 0.5 inch
Pitch (A) 12.7mm
Inside Width min (B) 7.85mm
Roller Diameter max (C) 7.95mm
Plate Height max (D) 11.9mm
Plate Width Inner max (E) 1.5mm
Plate Width Outer max (F) 1.5mm
Pin Diameter max (G) 3.96mm
Pin Length max (H1) 45.2mm
Connecting Link Extension max (J) 1.95mm
ISO606 Tensile Strength min 41700 N
Weight 1.74kg/m
