• 400X4SPA 400mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
  • 400X4SPA 400mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
1 2

SKU: 400SPA4-MB

400X4SPA 400mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)

400X4SPA 400mm Pitch Diameter SPA Section Tapered Locking Bush Type Pulley with 4 Grooves (Bush not Incl.)
$138.94 ex VAT
$138.94 ex VAT
Sale Sold out

In stock

Price Break
3+ $93.07
5+ $87.84
9+ $86.80
19+ $85.75
49+ $84.70
74+ $83.66
99+ $78.43
199+ $77.38
249+ $76.34
499+ $75.29
999+ $73.20

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Grooves:
4
Outside Diameter:
406.2mm
Pitch Diameter:
400mm
Max Bore:
75mm
Technical
Number of Grooves 4
Bush <a href="advanced_search_result.php?sort=2a&search_in_description=1&keywords=3020+tapered+locking+bush">3020 Click Here</a>
Pitch Diameter B 400mm
Overall Outer Diameter C 406.2mm
Max Bore A 75mm
Outer Hub Diameter E 159mm
Overall Sheave Depth F 65mm
Bush Seat Length G 51mm
Inner Recess Diameter D 365mm
Inner Recess Length H 7mm
