• 475X8SPC 475mm Pitch Diameter SPC Section Tapered Locking Bush Type Pulley with 8 Grooves (Bush not Incl.)
1 1

SKU: 475SPC8-MB

475X8SPC 475mm Pitch Diameter SPC Section Tapered Locking Bush Type Pulley with 8 Grooves (Bush not Incl.)

475X8SPC 475mm Pitch Diameter SPC Section Tapered Locking Bush Type Pulley with 8 Grooves (Bush not Incl.)
$655.67 ex VAT
$655.67 ex VAT
Sale Sold out

In stock

Price Break
3+ $439.19
5+ $414.52
9+ $409.58
19+ $404.65
49+ $399.71
74+ $394.78
99+ $370.11
199+ $365.17
249+ $360.24
499+ $355.30
999+ $345.43

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Major Brand - High Quality
Grooves:
8
Outside Diameter:
485.2mm
Pitch Diameter:
475mm
Max Bore:
125mm
Technical
Number of Grooves 8
Bush <a href="advanced_search_result.php?sort=2a&search_in_description=1&keywords=4535+tapered+locking+bush">4535 Click Here</a>
Pitch Diameter B 475mm
Overall Outer Diameter C 485.2mm
Max Bore A 125mm
Outer Hub Diameter E 265mm
Overall Sheave Depth F 213mm
Bush Seat Length G 89mm
Inner Recess Diameter D 418mm
Inner Recess Length H 62mm
