• 53201 Budget Single Thrust Ball Bearing with Spherical Housing Seat U201 12x28x13mm
1 1

SKU: 53201?EU

53201 Budget Single Thrust Ball Bearing with Spherical Housing Seat U201 12x28x13mm

53201 Budget Single Thrust Ball Bearing with Spherical Housing Seat U201 12x28x13mm
$21.87 ex VAT
$21.87 ex VAT
Sale Sold out

In stock

Price Break
10+ $14.65
19+ $13.82
29+ $13.66
39+ $13.49
49+ $13.33
74+ $13.16
99+ $12.34
199+ $12.18
249+ $12.01
499+ $11.85
999+ $11.52

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
12mm
Outside Diameter:
28mm
Width:
13mm
Technical
d 12mm
D 28mm
H1 13mm
Dynamic load C 13.3 kN
Static load Co 20.8 kN
Fatigue load limit Pu 0.77 kN
Minimum load factor A 0.0022
Reference speed 8000 rpm
Limiting Speed 11000 rpm
Weight 0.045 kg
Seating Washer U201
d1 28mm
D1 14mm
D2 20mm
D3 30mm
H 11.4mm
C 3.5mm
R 25mm
s 11.5mm
r1r2 min 0.6mm
da max 22mm
Da max 20mm
ra max 0.6mm
