• 53202 Budget Single Thrust Ball Bearing with Spherical Housing Seat U202 15x32x15mm
1 1

SKU: 53202?EU

53202 Budget Single Thrust Ball Bearing with Spherical Housing Seat U202 15x32x15mm

53202 Budget Single Thrust Ball Bearing with Spherical Housing Seat U202 15x32x15mm
$23.17 ex VAT
$23.17 ex VAT
Sale Sold out

In stock

Price Break
10+ $15.52
19+ $14.65
29+ $14.47
39+ $14.30
49+ $14.12
74+ $13.95
99+ $13.08
199+ $12.90
249+ $12.73
499+ $12.55
999+ $12.20

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
15mm
Outside Diameter:
32mm
Width:
15mm
Technical
d 15mm
D 32mm
H1 15mm
Dynamic load C 16.5 kN
Static load Co 27 kN
Fatigue load limit Pu 1 kN
Minimum load factor A 0.0038
Reference speed 7000 rpm
Limiting Speed 10000 rpm
Weight 0.063 kg
Seating Washer U202
d1 32mm
D1 17mm
D2 24mm
D3 35mm
H 13.3mm
C 4mm
R 28mm
s 12mm
r1r2 min 0.6mm
da max 25mm
Da max 24mm
ra max 0.6mm
