• 53207 Budget Single Thrust Ball Bearing with Spherical Housing Seat U207 35x62x22mm
1 1

SKU: 53207?EU

53207 Budget Single Thrust Ball Bearing with Spherical Housing Seat U207 35x62x22mm

53207 Budget Single Thrust Ball Bearing with Spherical Housing Seat U207 35x62x22mm
$39.09 ex VAT
$39.09 ex VAT
Sale Sold out

In stock

Price Break
10+ $26.18
19+ $24.71
29+ $24.42
39+ $24.12
49+ $23.83
74+ $23.54
99+ $22.07
199+ $21.77
249+ $21.48
499+ $21.18
999+ $20.59

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
35mm
Outside Diameter:
62mm
Width:
22mm
Technical
d 35mm
D 62mm
H1 22mm
Dynamic load C 35.1 kN
Static load Co 73.5 kN
Fatigue load limit Pu 2.7 kN
Minimum load factor A 0.028
Reference speed 4000 rpm
Limiting Speed 5600 rpm
Weight 0.28 kg
Seating Washer U207
d1 62mm
D1 37mm
D2 48mm
D3 65mm
H 19.87mm
C 7mm
R 50mm
s 24mm
r1r2 min 1mm
da max 51mm
Da max 48mm
ra max 1mm
