• 53210 Budget Single Thrust Ball Bearing with Spherical Housing Seat U210 50x78x26mm
1 1

SKU: 53210?EU

53210 Budget Single Thrust Ball Bearing with Spherical Housing Seat U210 50x78x26mm

53210 Budget Single Thrust Ball Bearing with Spherical Housing Seat U210 50x78x26mm
$51.15 ex VAT
$51.15 ex VAT
Sale Sold out

In stock

Price Break
10+ $34.26
19+ $32.34
29+ $31.95
39+ $31.57
49+ $31.18
74+ $30.80
99+ $28.87
199+ $28.49
249+ $28.10
499+ $27.72
999+ $26.95

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
50mm
Outside Diameter:
78mm
Width:
26mm
Technical
d 50mm
D 78mm
H1 26mm
Dynamic load C 49.4 kN
Static load Co 116 kN
Fatigue load limit Pu 4.3 kN
Minimum load factor A 0.069
Reference speed 3400 rpm
Limiting Speed 4500 rpm
Weight 0.47 kg
Seating Washer U210
d1 78mm
D1 52mm
D2 62mm
D3 82mm
H 23.49mm
C 7.5mm
R 64mm
s 32.5mm
r1r2 min 1mm
da max 67mm
Da max 62mm
ra max 1mm
