• 53216 Budget Single Thrust Ball Bearing with Spherical Housing Seat U216 80x115x33mm
1 1

SKU: 53216?EU

53216 Budget Single Thrust Ball Bearing with Spherical Housing Seat U216 80x115x33mm

53216 Budget Single Thrust Ball Bearing with Spherical Housing Seat U216 80x115x33mm
$126.66 ex VAT
$126.66 ex VAT
Sale Sold out

In stock

Price Break
10+ $84.84
19+ $80.08
29+ $79.12
39+ $78.17
49+ $77.22
74+ $76.26
99+ $71.50
199+ $70.54
249+ $69.59
499+ $68.64
999+ $66.73

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
80mm
Outside Diameter:
115mm
Width:
33mm
Technical
d 80mm
D 115mm
H1 33mm
Dynamic load C 76.1 kN
Static load Co 208 kN
Fatigue load limit Pu 7.65 kN
Minimum load factor A 0.22
Reference speed 2400 rpm
Limiting Speed 3400 rpm
Weight 1.1 kg
Seating Washer U216
d1 115mm
D1 82mm
D2 98mm
D3 120mm
H 29.5mm
C 10mm
R 90mm
s 46mm
r1r2 min 1mm
da max 101mm
Da max 98mm
ra max 1mm
