• 53217 Budget Single Thrust Ball Bearing with Spherical Housing Seat U217 85x125x37mm
1 1

SKU: 53217?EU

53217 Budget Single Thrust Ball Bearing with Spherical Housing Seat U217 85x125x37mm

53217 Budget Single Thrust Ball Bearing with Spherical Housing Seat U217 85x125x37mm
$145.82 ex VAT
$145.82 ex VAT
Sale Sold out

In stock

Price Break
10+ $97.68
19+ $92.19
29+ $91.10
39+ $90.00
49+ $88.90
74+ $87.80
99+ $82.32
199+ $81.22
249+ $80.12
499+ $79.02
999+ $76.83

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
85mm
Outside Diameter:
125mm
Width:
37mm
Technical
d 85mm
D 125mm
H1 37mm
Dynamic load C 97.5 kN
Static load Co 275 kN
Fatigue load limit Pu 9.8 kN
Minimum load factor A 0.39
Reference speed 2200 rpm
Limiting Speed 3000 rpm
Weight 1.5 kg
Seating Washer U217
d1 125mm
D1 88mm
D2 105mm
D3 130mm
H 33.1mm
C 11mm
R 100mm
s 52mm
r1r2 min 1mm
da max 109mm
Da max 105mm
ra max 1mm
