SKU: 53222?EU

53222 Budget Single Thrust Ball Bearing with Spherical Housing Seat U222 110x160x45mm

Name: 53222 Budget Single Thrust Ball Bearing with Spherical Housing Seat U222 110x160x45mm
Brand: Gen
SKU: 53222?EU
Price: 263.11 USD
Availability: InStock

$263.11 ex VAT

Sale Sold out

In stock

Price Break

10+ $176.24

19+ $166.34

29+ $164.36

39+ $162.38

49+ $160.40

74+ $158.42

99+ $148.52

199+ $146.54

249+ $144.56

499+ $142.58

999+ $138.62

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 110mm
Outside Diameter:: 160mm
Width:: 45mm

Technical

d	110mm
D	160mm
H1	45mm
Dynamic load C	130 kN
Static load Co	390 kN
Fatigue load limit Pu	12.5 kN
Minimum load factor A	0.79
Reference speed	1700 rpm
Limiting Speed	2400 rpm
Weight	2.91 kg
Seating Washer	U222
d1	160mm
D1	113mm
D2	135mm
D3	165mm
H	40.2mm
C	14mm
R	125mm
s	65mm
r1r2 min	1.1mm
da max	140mm
Da max	135mm
ra max	1mm
