SKU: 53224+U224-SKF
SKF 53224 Single Thrust Ball Bearing with Spherical Housing Seat U224 120x170x46mm
SKF 53224 Single Thrust Ball Bearing with Spherical Housing Seat U224 120x170x46mm
Out of stock
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 120mm
- Outside Diameter:
- 170mm
- Width:
- 46mm
Technical
Technical
| d | 120mm |
|---|---|
| D | 170mm |
| H1 | 46mm |
| Dynamic load C | 140 kN |
| Static load Co | 440 kN |
| Fatigue load limit Pu | 13.4 kN |
| Minimum load factor A | 1 |
| Reference speed | 1600 rpm |
| Limiting speed | 2200 rpm |
| Weight | 3.2 kg |
| Seating washer | U224 |
| d1 | 170mm |
| D1 | 123mm |
| D2 | 145mm |
| D3 | 175mm |
| H | 40.8mm |
| C | 15mm |
| R | 125mm |
| s | 61mm |
| r1r2 min | 1.1mm |
| da max | 150mm |
| Da max | 145mm |
| ra max | 1mm |
