• 53308 Budget Single Thrust Ball Bearing with Spherical Housing Seat U308 40x78x31mm
1 1

SKU: 53308?EU

53308 Budget Single Thrust Ball Bearing with Spherical Housing Seat U308 40x78x31mm

53308 Budget Single Thrust Ball Bearing with Spherical Housing Seat U308 40x78x31mm
$57.96 ex VAT
$57.96 ex VAT
Sale Sold out

In stock

Price Break
10+ $38.82
19+ $36.64
29+ $36.20
39+ $35.77
49+ $35.33
74+ $34.89
99+ $32.71
199+ $32.28
249+ $31.84
499+ $31.40
999+ $30.53

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
40mm
Outside Diameter:
78mm
Width:
31mm
Technical
d 40mm
D 78mm
H1 31mm
Dynamic load C 61.8 kN
Static load Co 122 kN
Fatigue load limit Pu 4.5 kN
Minimum load factor A 0.077
Reference speed 3000 rpm
Limiting Speed 4300 rpm
Weight 0.67 kg
Seating Washer U308
d1 78mm
D1 42mm
D2 60mm
D3 82mm
H 28.5mm
C 8.5mm
R 64mm
s 28mm
r1r2 min 1mm
da max 63mm
Da max 60mm
ra max 1mm
