• 53310 Budget Single Thrust Ball Bearing with Spherical Housing Seat U310 50x95x37mm
1 1

SKU: 53310?EU

53310 Budget Single Thrust Ball Bearing with Spherical Housing Seat U310 50x95x37mm

53310 Budget Single Thrust Ball Bearing with Spherical Housing Seat U310 50x95x37mm
$91.36 ex VAT
$91.36 ex VAT
Sale Sold out

In stock

Price Break
10+ $61.19
19+ $57.76
29+ $57.07
39+ $56.38
49+ $55.69
74+ $55.01
99+ $51.57
199+ $50.88
249+ $50.19
499+ $49.51
999+ $48.13

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
EU Budget - Economy Quality
Inside Diameter:
50mm
Outside Diameter:
95mm
Width:
37mm
Technical
d 50mm
D 95mm
H1 37mm
Dynamic load C 88.4 kN
Static load Co 190 kN
Fatigue load limit Pu 6.95 kN
Minimum load factor A 0.19
Reference speed 2600 rpm
Limiting Speed 3600 rpm
Weight 1.2 kg
Seating Washer U310
d1 95mm
D1 52mm
D2 72mm
D3 100mm
H 34.3mm
C 11mm
R 72mm
s 28mm
r1r2 min 1.1mm
da max 77mm
Da max 72mm
ra max 1mm
