53313 Budget Single Thrust Ball Bearing with Spherical Housing Seat U313 65x115x43mm

Name: 53313 Budget Single Thrust Ball Bearing with Spherical Housing Seat U313 65x115x43mm
Brand: Gen
SKU: 53313?EU
Price: 223.23 USD
Availability: InStock

$223.23 ex VAT

Sale Sold out

In stock

Price Break

10+ $149.53

19+ $141.13

29+ $139.45

39+ $137.77

49+ $136.09

74+ $134.41

99+ $126.01

199+ $124.33

249+ $122.65

499+ $120.97

999+ $117.61

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 65mm
Outside Diameter:: 115mm
Width:: 43mm

Technical

d	65mm
D	115mm
H1	43mm
Dynamic load C	106 kN
Static load Co	240 kN
Fatigue load limit Pu	8.8 kN
Minimum load factor A	0.3
Reference speed	2000 rpm
Limiting Speed	3000 rpm
Weight	1.89 kg
Seating Washer	U313
d1	115mm
D1	67mm
D2	90mm
D3	120mm
H	39.4mm
C	12.5mm
R	90mm
s	38.5mm
r1r2 min	1.1mm
da max	95mm
Da max	90mm
ra max	1mm
