SKF 54308 Double Thrust Ball Bearing with Spherical Housing Washers 30x78x59mm

Name: SKF 54308 Double Thrust Ball Bearing with Spherical Housing Washers 30x78x59mm
Brand: SKF
SKU: 54308-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Double Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of five parts, a top, bottom and middle plate with annular grooves in them and two caged ball bearing assemblies that are sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in two directions. Clearance is provided in the bore of Centre of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: SKF - High Quality
Inside Diameter:: 30mm
Outside Diameter:: 78mm
Width:: 59mm

Technical

d	30mm
D	78mm
H1	59mm
Dynamic load C	61.8 kN
Static load Co	122 kN
Fatigue load limit Pu	4.5 kN
Minimum load factor A	0.077
Reference speed	3000 rpm
Limiting speed	4300 rpm
Weight	1.17 kg
Seating washer	U308
D1	42mm
D2	60mm
D3	82mm
H	54.1mm
B	12mm
C	8.5mm
R	64mm
s	23.5mm
r1r2	1mm
r3r4	0.6mm
da	40mm
Da max	60mm
ra max	1mm
rb max	0.6mm
