• High-Performance High Capacity 4 Bolt Top Mounted Square Ball Transfer Unit with 25.4mm Stainless Steel Ball - Load Capacity 121.94kg - Allow 2-3 Days
1 1

SKU: 570-402A

High-Performance High Capacity 4 Bolt Top Mounted Square Ball Transfer Unit with 25.4mm Stainless Steel Ball - Load Capacity 121.94kg - Allow 2-3 Days

High-Performance High Capacity 4 Bolt Top Mounted Square Ball Transfer Unit with 25.4mm Stainless Steel Ball - Load Capacity 121.94kg - Allow 2-3 Days
$101.46 ex VAT
$101.46 ex VAT
Sale Sold out

In stock

Price Break
4+ $66.63
9+ $62.89
14+ $62.14
19+ $61.39
49+ $60.64
74+ $59.89
99+ $56.15
199+ $55.40
249+ $54.65
499+ $53.90
999+ $52.41

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Brand / Quality:
Simply Ball Transfer Units
Outside Diameter:
25.4mm
Technical
--- Dimensions
Ball Diameter 25.4mm
Y mm 41.3mm
W mm 35.8mm
D mm 44.5mm
FXF mm 57.2mm
CXC mm 44.5mm
T mm 4.8mm
E(Dia) mm 4x5.6mm
--- Loads and Speeds
Load Capacity 121.94 kg
Load capacity Ibs 268.67 lbs
Weight 0.75 kg
--- Materials
Material Body: Zinc Plated Mild Steel<br>Ball: 420 Stainless Steel
Mounting Type Square
