SKU: 6006ZZC3-NSK
NSK 6006ZZC3 Metal Shielded Deep Groove Ball Bearing 30x55x13mm
Equivalent to: 6006ZZEC3 60062ZC3 6006.2ZC3 60062ZRC3 6006FFC3
In stock
Price Break
Couldn't load pickup availability
Share this product
Description
Metal Shielded Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing.
Shields can be removed for applications that don't require a shield or only require 1 shield.
Benefits: Provides light mechanical protection, limits moisture and dirt ingress, lubricated for life, cost-effective solution.
- Brand / Quality:
- NSK - High Quality
- Inside Diameter:
- 30mm
- Outside Diameter:
- 55mm
- Width:
- 13mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- C3
Technical
| d | 30mm |
|---|---|
| D | 55mm |
| B | 13mm |
| r min | 1mm |
| Dynamic load Cr | 13200 N (1350 kgf) |
| Static load Cor | 8300 N (845 kgf) |
| Factor | 14.7 |
| Speed in grease | 13000 rpm |
| Speed in oil | 15000 rpm |
| Weight | 0.116 kg |
