SKU: 60x70x6_UOP_NAK
NAK 60x70x6mm UOP Polyurethane Piston Seal - Allow 7-10 Days
- Regular price
- $5.28 ex VAT
- Sale price
- $5.28
- Regular price
-
Not in stock
Quantity Price Breaks
10
$4.70
19
$4.44
29
$4.38
39
$4.33
49
$4.28
74
$4.22
99
$3.96
199
$3.91
249
$3.85
499
$3.80
999
$3.70
SKU:
60x70x6_UOP_NAK
NAK 60x70x6mm UOP Polyurethane Piston Seal - Allow 7-10 Days
- Regular price
- $5.28 ex VAT
- Sale price
- $5.28
- Regular price
-
Description
NAK UOP Piston Seals: The UOP piston seal from NAK is a high-performance, dual-lip polyurethane seal designed for use in dynamic hydraulic applications. Engineered for installation in both single-acting and double-acting cylinders, it delivers outstanding sealing performance, low friction, and long-term fluid retention under a wide range of pressures and operating conditions.
Benefits: Easy installation, stable performance under fluctuating pressures, excellent sealing efficiency
Technical
| d | = | 60mm |
| D | = | 70mm |
| L | = | 7mm |
| h | = | 6mm |
| C | = | 2.5mm |
| Inside Diameter Tolerance | = | h10 |
| Outside Diameter Tolerance | = | H9 |
| Length Tolerance | = | 0.2mm |
| Pressure (max) | = | 40 Mpa |
| Sliding Speed (max) | = | 0.5 m/s |
| Temperature | = | -40 Deg C to +100 Deg C |
| Colour | = | Blue |
