SKU: 6200-2Z/C3-KOY
KOYO 62002ZC3 Metal Shielded Deep Groove Ball Bearing 10x30x9mm
Equivalent to: 6200ZZEC3 6200ZZC3 6200.2ZC3 6200KDDC3 6200DDC3 62002ZRC3 6200FFC3
In stock
Price Break
Couldn't load pickup availability
Share this product
Description
|
KOYO Metal Shielded Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing. |
- Brand / Quality:
- Koyo - High Quality
- Inside Diameter:
- 10mm
- Outside Diameter:
- 30mm
- Width:
- 9mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- C3
Technical
| Inside Diameter d | 10mm |
|---|---|
| Outside Diameter D | 30mm |
| Width B | 9mm |
| Min radius r | 0.6mm |
| Dynamic load | 5.1 kN |
| Static load | 2.4 kN |
| Max speed in oil | 29000 rpm |
| Max speed in grease | 16000 rpm |
